Sony BRC-X400 (Black)

  • Doprava zdarma
Kód zboží: BRC-X400/B

Sony BCR-X400 je 4K PTZ kamera so 40x zoomom, 1/2.5" Exmor R CMOS senzorom, podporou 3G-SDI, HDMI a NDI®|HX. Ovládanie cez VISCA protocol alebo Ethernet a podpora PoE+. Dostupná v čiernej a bielej farbe.

Více informací

155 490 Kč s DPH 128 504 Kč bez DPH
Přidat do porovnání Historie ceny
Dostupnost
na dotaz
Kód zboží:
BRC-X400/B
Přidat do porovnání Historie ceny

Sony SRG-X400 (Black)

71 790 Kčbez DPH 59 331 Kč

Sony SRG-X120 (Black)

55 890 Kčbez DPH 46 190 Kč

Top příslušenství pro Sony BRC-X400 (Black)

Sony RM-IP500 (AC)

  • Doprava zdarma
SONY RM-IP500 (AC) je dálkový ovladač určený pro efektivní a přesné ovládání více
98 690 Kč
K odeslání 1 ks

Sony RM-IP10

  • Doprava zdarma
IP jednotka dálkového ovládání pro kamery BRC, SRG.
47 590 Kč
na dotaz

Skaarhoj PTZ Extreme w/Blue Pill Inside

  • Doprava zdarma
PTZ Extreme w/Blue Pill Inside je dokonalý ovladač pro víceosé robotické systémy.
118 490 Kč
14-30 dní
Popis produktu SPECIFIKACE OBSAH BALENÍ

Popis produktu

Sony BCR-X400 je 4K PTZ kamera so 40x zoomom, 1/2.5" Exmor R CMOS senzorom, podporou 3G-SDI, HDMI a NDI®|HX. Ovládanie cez VISCA protocol alebo Ethernet a podpora PoE+. Dostupná v čiernej a bielej farbe.

Capture every point of view in 4K with excellent picture quality and efficient IP production workflow

The versatile BRC-X400 PTZ camera is ideal for use in a wide range of environments - from broadcast studios and remote on-air suites to sports stadiums, arenas, houses of worship and lecture halls.

The camera's 1/2.5-type Exmor R CMOS sensor captures broadcast quality 4K images with excellent sensitivity, very low noise and rich, natural colour reproduction. It's complemented by the integrated high-resolution lens that offers a powerful zoom capability of up to 80x in Full HD*** (30x in 4K), with an expansive approx. 70 degree wide angle coverage to capture every point of view.

Efficient IP-based live production is augmented with support for NDI®|HX* (via optional license), allowing flexible configuration with other networked NDI-enabled devices.

Images also can be reviewing remotely via a web browser, with support for RTSP (Real Time Streaming Protocol) and RTMP** (Real Time Messaging Protocol) ensuring smooth, stable streaming of video plus audio (from an optional microphone, available separately) over an IP network.

Installation and set-up is easy, with a new Scene File function allowing the same settings to be applied to multiple cameras. Convenient integration in multi-camera live events is also simplified with genlock support and an 'on-air' tally lamp.

* NDI® is a registered trademark of NewTek, Inc.
** Available through future upgrade planned in early 2020
*** With Clear Image Zoom and Tele Convert Mode

Note: When using RM-IP500 firmware should be updated to V2.10 and for RM-IP10, firmware should be updated to V2.17.

Excellent 4K images, even in low light
The sensitive 1/2.5-type Exmor R sensor captures high-quality 4K images with very low noise, even in dimly-lit environments.

Up to 80x zoom
Powerful zoom up to 80x (in FHD) allows frame-filling close-ups with fine details seen clearly. Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings.

Wide viewing angle
Cover the whole scene in sports arenas and lecture theatres with a horizontal viewing angle of approx. 70 degrees.

Support for NDI®*|HX
NDI®|HX compatibility (via optional license) supports efficient IP-based live production, allowing flexible configuration with other networked NDI-enabled devices.
* NDI® is a registered trademark of NewTek, Inc. Network services, content, and the [operating system and] software of this Product may be subject to individual terms and conditions and changed, interrupted or discontinued at any time and may require fees, registration and credit card information.

Multiple control protocols
PTZ and other camera functions can be controlled remotely via S700PTP, CGI and VISCA protocols.

Remote viewing
View pictures remotely over the Internet from a web browser, with support for RTSP (Real Time Streaming Protocol) and RTMP* (Real Time Messaging Protocol).
*Available through future upgrade planned in early 2020

Simpler installation, lower costs
A single IP cable carries camera power, video image output and control signals to simplify installation and reduce cabling costs.

Ideal for live production
Genlock allows seamless multi-camera switching in live events. The camera's inbuilt tally lamp is ideal for live productions and reality shows.

Fast, fuss-free set-up
The new Scene File* function can apply the same camera settings among multiple cameras for fast set-up.

*Available through future upgrade planned in early 2020

OBSAH BALENÍ

  • AC power adaptor (1)
  • IR Remote Commander Unit (1)
  • Ceiling bracket (2)
  • Wire rope (1)
  • Screw M3 x 8 (9)
  • Screw M2.6 x6 BLACK (1)
  • HDMI cable fixing plate (1)
  • Safety regulation (1)
  • Download site information (1)
  • Warranty (1)

SPECIFIKACE

Camera

Image Sensor
1/2.5 Exmor R CMOS

Image Sensor (Number of Effective Pixels)
Approx. 8.5M pixels

Signal System
2160/29.97p, 25p, 23.98p (HDMI and IP only)
1080/59.94p, 50p, 29.97p, 25p, 23.98p
1080/59.94i, 50i
720/59.94p, 50p

4K capability
Yes (built-in 4K functions)

Minimum Illumination (50IRE)
1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)

Horizontal Resolution
1700 TV line (Center) (4K)
1000 TV line (Center) (FHD)

Gain
Auto/Manual (0 to +48 dB)
High Sensitivity On

Shutter Speed
1/1 to 1/10000 sec (59.94 Hz system)
1/1 to 1/10000 sec (23.98 Hz system)
1/1 to 1/10000 sec (50 Hz system)

Exposure Control
Auto/Manual/Priority AE (Shutter, Iris)

White Balance
Auto1/Auto2/One Push WB/Indoor/Outdoor/Manual

Optical Zoom
20x

Clear Image Zoom
4K: 1.5x, FHD: 2x

Digital Zoom
FHD: 12x

Tele Convert Mode
2x (1920 x 1080 only)

Focusing System
Auto/Manual

Horizontal Viewing Angle
Approx. 70.0 degree (Wide)

Focal Length
f=4.4 mm (Wide) to 88.0 mm (Tele)
F2.0 to F3.8

Minimum Object Distance
80 mm (Wide)~
800 mm (Tele)

Pan/Tilt Angle
Pan: ±170°
Tilt: +90°/-20°

Pan/Tilt Speed (Max.)
Pan: 300 degrees/sec
Tilt: 126 degrees/sec

Pan/Tilt Speed
Pan: 1.1° to 101°/s
Tilt: 1.1° to 91°/s

Pan/Tilt Speed (Slow)
Pan: 0.5° to 60°/s
Tilt: 0.5° to 60°/s

Pan/Tilt Slow Mode
yes

Preset Position
256 (CGI)
100 (VISCA)

Picture Freeze Preset
Yes

Preset Mode1/Mode2
Yes

Network

IP Video resolution
3840x2160, 1920x1080, 1280x720, 720x576, 720x480, 640x360

Compression Format
H.264 High/Main/Baseline Profile
H.265: Main Profile

Maximum Frame Rate
H.264: 60fps
H.265: 60fps

Bitrate Compression Mode
CBR/VBR (selectable)

Range of Bitrate Setting
512 Kbps ~50 Mbps

Adaptive Rate Control
No

Multi Streaming Capability
3

Maximum Number of Clients
5

Protocols
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, UPnP, VISCA over IP

NDI®|HX Capability
Yes Optional (requires a license)

Camera Features

Auto ICR
No

Day/Night
Yes

Wide-D
No

Visibility Enhancer
Yes

Image Stabilization
Yes

Image Flip
Yes

Auto Power Off
No

Night Power Off
No

Picture Profile Preset
Yes

ND Filter
No

Color Gain
Yes (15 step)

Color Hue
Yes (15 step)

Color Matrix
Yes (Standard, HIGH SAT, FL LIGHT, MOVIE, STILL, CINEMA, PRO, ITU709, B&W)

Gamma
Standard/Straight/512Pattern/MOVIE/STILL/CINE1/CINE2/CINE3/CINE4/ITU709

Gamma Level
Yes (15 step)

Black-> Black level
Yes (97 step)

Black Gamma
Yes (15 step)

Knee Point
Yes (15 step)

Knee Slope
Yes (15 step)

Flicker Cancel
On/Off

B&W
Yes

Color Bar
On/Off

Web UI

Ver Up
Yes

Audio

Channel
2ch

Audio Codec
AAC LC 128kbps/ST (IP)
AAC LC 256kbps/ST (IP)

Setting Option
Auto Gain Control (AGC): On/Off
Equalizer: Off/Low Cut/Voice enhancement
Input selection: Microphone/Line
Mic volume: -10~+10 (21 steps)
Audio codec

Embedded Audio in Baseband Video
Yes (3G-SDI, HDMI)

Embedded Audio in IP Streaming
Yes

Interface

4K Video Output
HDMI x1 and IP (streaming) x1

HD Video Output
3G-SDI x1, HDMI x1, IP (streaming) x1

SD Video Output
No

HDMI Color Space
YCbCr, 4:2:2 8 bit
RGB, 4:4:4 8 bit

Camera Control Interface
VISCA RS-422 RJ45 (In/Out)
VISCA over IP RJ-45
S700PTP RJ-45

IR Remote Control
Yes

Microphone Input
Mini-phone (?3.5mm) x2 (Mic/Line Selectabe)

Sync. System
EXT/INT

External Sync. Input
BNC, 75?, HD 3-level sync, SD Black Burst

Tally
Front x 1

Power Connector Type
IEC60130-10 (JEITA standard RC-5320A) TYPE4

General

Power Requirements
DC 12V (DC 10.8 to 13.2V), PoE+ (IEEE802.3at compliant)

Power Consumption
25.5 W (Max)

Operating Temperature
0 °C to 40 °C
32 °F to 104 °F

Storage Temperature
-20 °C to +60 °C
-4 °F to +140 °F

Dimensions (W x H x D)*1
158.4 x 177.5 x 200.2 mm
6 1/4 x 7 x 8 inch

Mass
Approx. 1.8 kg
3 lb 15.5 oz

Optional Card Slots
No

Body Color
White/Black

Wide Conversion Lens Attachable
No

Size of Screw Hole for Tripod
1/4-20UNC x1

Mountable Angle
< ±15°

Ceiling Mount
Yes

Supplied Accessories
AC power adaptor (1)
IR Remote Commander Unit (1)
Ceiling bracket (2)
Wire rope (1)
Screw M3 x 8 (9)
Screw M2.6 x6 BLACK (1)
HDMI cable fixing plate (1)
Safety regulation (1)
Download site information (1)
Warranty (1)



Parametry

Parametry

Výrobce: SONY
Kategorie: PTZ

Hlavní parametry

Velikost snímače kamery1/2.5"
RozlišeníUHD
RozlišeníFull HD
Zoom30x
Typ bajonetuintegrovaný objektiv
VýstupHDMI
Výstup3G SDI

Ostatní parametry

ProvedeníPTZ
FPSUHD 30fps
FPSHD 60fps
FPSHD 50fps
Světelnost objektivu2f
Min. ohnisková vzdálenost4.4mm
Max. ohnisková vzdálenost88mm
Barevná hloubka8 bit
Barevná hloubka10 bit
Další funkcePTZ
Další funkceStreaming
Další funkcePoE
Ovládací protokolRS-422
Ovládací protokolVISCA
