IP 4K PTZ kamera s 12x zoomom a schopnosťou NDI®*|HX výstupu.
Schopnosť kamery pracovať v rozlíšení 4K je podmienené zakúpením licencie SRGL-4K (NIE JE SÚČASŤOU BALENIA).
Schopnosť kamery používať NDI®*|HX výstup je podmienený zakúpením licencie od spoločnosti Newtek (NIE JE SÚČASŤOU BALENIA).
IP 4K PTZ kamera s 12x zoomom a schopnosťou NDI®*|HX výstupu.
Schopnosť kamery pracovať v rozlíšení 4K je podmienené zakúpením licencie SRGL-4K (NIE JE SÚČASŤOU BALENIA).
Schopnosť kamery používať NDI®*|HX výstup je podmienený zakúpením licencie od spoločnosti Newtek (NIE JE SÚČASŤOU BALENIA).
Capture every point of view with excellent 4K picture quality and efficient IP production workflow
The versatile SRG-X120 remotely controlled PTZ camera is ideal for a wide range of applications - from classrooms and meeting spaces and medical environments.
The camera's 1/2.5-type Exmor R CMOS sensor captures up to 4K resolution images (requires optional license) with excellent sensitivity, very low noise and rich, natural colour reproduction. It's complemented by the integrated high-resolution 12x zoom lens that offers an expansive 70 degree wide angle coverage to capture every point of view.
High speed movement during preset recall captures the speaker's every movement, while Picture Freeze during transitions ensures your audience isn't disturbed by rapid camera movements. PTZ Motion Sync** function allows smooth blending of separate pan, tilt and zoom movements for seamless, professional-looking transition.
Efficient IP-based live production is augmented with support for NDI®|HX (via optional license), allowing flexible configuration with other networked NDI®-enabled devices.
Images also can be reviewing remotely via a web browser, with support for RTSP (Real Time Streaming Protocol) and RTMP** (Real Time Messaging Protocol) ensuring smooth, stable streaming of video plus audio (from an optional microphone, available separately) over an IP network.
*NDI® is a registered trademark of NewTek, Inc.
**Available through future upgrade planned in early 2020
Note 1: This product contains pre-installed software and requires the purchase of licence keys to activate some functions.
Note 2: When using RM-IP500 firmware should be updated to V2.10 and for RM-IP10, firmware should be updated to V2.17.
Excellent images, even in low light
The sensitive 1/2.5-type Exmor R sensor captures high-quality images with very low noise, even in dimly-lit environments.
4K upgrade option
Upgrade to 4K shooting via optional license (availability planned in early 2020).
Up to 40x zoom
Powerful zoom up to 40x (in Full HD) allows finely detailed frame-filling close-ups. Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings.
Wide viewing angle
Cover the whole scene in meetings and lecture theatres with a horizontal viewing angle of approx. 70 degrees.
Ideal for lecture caputure
Use the camera in conjunction with the AI-based REA-C1000 Edge Analytics Appliance to smoothly track the speaker's movements and automatically generate a cut-out image of speaker.
High speed movement and Picture Freeze Preset
Accurately capture the presenter's movements with maximum 300°/sec pan and tilt movement during preset recall. Picture Freeze Preset maintains a steady image while the camera moves to a new preset position – with no uncomfortable transitions for your audience.
Smooth pan-tilt-zoom
PTZ Motion Sync function allows smooth blending of separate pan, tilt and zoom movements for seamless, professional-looking transitions.
Simpler installation, lower costs
A single network cable carries camera power, video output and control signals to simplify installation and reduce cabling costs.
Support for NDI®*|HX
NDI®|HX compatibility (via optional license) enables cost-effictive school studio system integration, allowing flexible configuration with other networked NDI®-enabled devices.
* NDI® is a registered trademark of NewTek, Inc. Network services, content, and the [operating system and] software of this Product may be subject to individual terms and conditions and changed, interrupted or discontinued at any time and may require fees, registration and credit card information.
Image Sensor
1/2.5 type ExmorR CMOS
Image Sensor (Number of Effective Pixels)
Approx. 8.5M pixels
Signal System
2160 (*1)/29.97p, 25p, 23.98p (HDMI and IP only)
1080/59.94p, 50p, 29.97p, 25p, 23.98p
1080/59.94i, 50i
720/59.94p, 50p
4K capability
Yes (requires 4K Option license)
Minimum Illumination (50IRE)
1.6 lux (1/30s 50IRE F2 high-sensitivity OFF)
Horizontal Resolution
1700 TV line (Center) (4K(*1))
1000 TV line (Center) (FHD)
Gain
Auto/Manual (0 to +48 dB)
High Sensitivity On
Shutter Speed
1/1 to 1/10000 sec (59.94 Hz system)
1/1 to 1/10000 sec (23.98 Hz system)
1/1 to 1/10000 sec (50Hz system)
Exposure Control
Auto/Manual/Priority AE (Shutter, Iris)
White Balance
Auto1/Auto2/One Push WB/Indoor/Outdoor/Manual
Optical Zoom
12x
Clear Image Zoom
No
Digital Zoom
No
Tele Convert Mode
No
Focusing System
Auto/Manual
Horizontal Viewing Angle
Approx. 70.0 degree (Wide)
Focal Length
f=4.4mm (Wide) to 52.8mm (Tele)
F2.0 to F3.7
Minimum Object Distance
80 mm (Wide)~
400 mm (Tele)
Pan/Tilt Angle
Pan: ±170°
Tilt: +90°/-20°
Pan/Tilt Speed (Max.)
Pan: 300 degrees/sec
Tilt: 126 degrees/sec
Pan/Tilt Speed
Pan: 1.1° to 101°/s
Tilt: 1.1° to 91°/s
Pan/Tilt Speed (Slow)
Pan: 0.5° to 60°/s
Tilt: 0.5° to 60°/s
Pan/Tilt Slow Mode
Yes
Preset Position
256 (CGI)
100 (VISCA)
Picture Freeze Preset
Yes
Preset Mode1/Mode2
No
IP Video resolution
3840x2160 (*1), 1920x1080, 1280x720, 720x576, 720x480, 640x360
Compression Format
H.264 High/Main/Baseline Profile H.265: Main Profile
Maximum Frame Rate
H.264: 60fps
H.265: 60fps
Bitrate Compression Mode
CBR/VBR (selectable)
Range of Bitrate Setting
512Kbps~50 Mbps
Adaptive Rate Control
No
Multi Streaming Capability
3
Maximum Number of Clients
5
Protocols
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, UPnP, VISCA over IP
NDI®|HX Capability
Yes Optional (requires a license)
Auto ICR
No
Day/Night
Yes
Wide-D
No
Visibility Enhancer
Yes
Image Stabilization
Yes
Image Flip
Yes
Auto Power Off
No
Night Power Off
No
Picture Profile Preset
No
ND Filter
No
Color Gain
No
Color Hue
No
Color Matrix
No
Gamma
No
Gamma Level
No
Black-> Black level
No
Black Gamma
No
Knee Point
No
Knee Slope
No
Flicker Cancel
On/Off
B&W
No
Color Bar
No
Ver Up
Yes
Channel
2ch
Audio Codec
AAC LC 128 kbps/ST (IP)
AAC LC 256 kbps/ST (IP)
Setting Option
Auto Gain Control (AGC): On/Off
Equalizer: Off/Low Cut/Voice enhancement
Input selection: Microphone/Line
Mic volume: -10~+10 (21 steps)
Audio codec
Embedded Audio in Baseband Video
Yes (3G-SDI, HDMI)
Embedded Audio in IP Streaming
Yes
4K Video Output
(*1) HDMI x1 and IP (streaming) x1
HD Video Output
3G-SDI x1, HDMI x1, IP (streaming) x1
SD Video Output
No
HDMI Color Space
YCbCr, 4:2:2 8 bit
RGB, 4:4:4 8 bit
Camera Control Interface
VISCA RS-422 RJ45 (In/Out)
VISCA over IP RJ-45
IR Remote Control
Yes
Microphone Input
Mini-phone (?3.5mm) x2, (Mic/Line Selectabe)
Sync. System
INT
External Sync. Input
No
Tally
No
Power Connector Type
IEC60130-10 (JEITA standard RC-5320A) TYPE4
Power Requirements
DC 12V (DC 10.8 to 13.2V), PoE+ (IEEE802.3at compliant)
Power Consumption
25.5W (Max)
Operating Temperature
0 °C to 40 °C
32 °F to 104 °F
Storage Temperature
-20 °C to +60 °C
-4 °F to +140 °F
Dimensions (W x H x D)*2
158.4 x 177.5 x 200.2 mm
6 1/4 x 7 x 8 inch
Mass
Approx. 1.8 kg
3 lb 15.5 oz
Optional Card Slots
No
Body Color
White/Black
Wide Conversion Lens Attachable
No
Size of Screw Hole for Tripod
1/4-20UNC x1
Mountable Angle
< ±15°
Ceiling Mount
Yes
Supplied Accessories
AC power adaptor (1)
IR Remote Commander Unit (1)
Ceiling bracket (2)
Wire rope (1)
Screw M3 x 8 (9)
Screw M2.6 x6 BLACK (1)
HDMI cable fixing plate (1)
Safety regulation (1)
Download site information (1)
Warranty (1)
*1 Will be available from early 2020, after an upgrade, via a 4K Option license
*2 The values for dimensions are approximate
Výrobce: | SONY |
Kategorie: | PTZ |
Velikost snímače kamery | 1/2.5" |
Rozlišení | Full HD |
Rozlišení | HDV (720p) |
Zoom | 12x |
Typ bajonetu | integrovaný objektiv |
Výstup | HDMI |
Výstup | 3G SDI |
Provedení | PTZ |
FPS | HD 60fps |
FPS | HD 50fps |
Světelnost objektivu | 2f |
Min. ohnisková vzdálenost | 4.4mm |
Max. ohnisková vzdálenost | 52.8mm |
Barevná hloubka | 8 bit |
Barevná hloubka | 10 bit |
Další funkce | Streaming |
Ovládací protokol | RS-422 |
Ovládací protokol | VISCA |
